IMCF Fluoroplastic Magnetic Drive Pump
IMCF Fluoroplastic Magnetic Drive Pump
The IMCF Fluoroplastic Magnetic Drive Pump combines the zero-leakage benefit of magnetic drive technology with fluoroplastic (PTFE/PVDF) wetted parts to handle the most aggressive chemical media. The fluoroplastic lining provides corrosion resistance against virtually all acids, alkalis, oxidizing agents, and organic solvents.
The hermetically sealed sealless design eliminates mechanical shaft seals as the primary emission source, making this pump compliant with the strictest emission regulations (EU Directive 2010/75/EU, EPA Method 21) for volatile organic compounds (VOCs) and toxic materials.
Available in PTFE-lined, solid PTFE, and PVDF-lined variants to suit temperature and media requirements. Containment shell options include reinforced PTFE and Hastelloy for high-pressure applications.
Product Details
| Type | Magnetic drive (sealless), centrifugal |
| Wetted Materials | PTFE / PVDF / Hastelloy C (containment) |
| Drive | Neodymium magnet coupling |
| Flow Rate | 0.5 β 80 mΒ³/h |
| Head | 5 β 70 m |
| Temperature | Up to +120Β°C (PTFE), +90Β°C (PVDF) |
| Media | All acids, alkalis, solvents, oxidizers |
| Emission | Zero VOC emission, EPA Method 21 compliant |
