FZB Fluoroplastic Self-Priming Pump
FZB Fluoroplastic Self-Priming Pump
The FZB Fluoroplastic Self-Priming Pump combines the convenience of self-priming operation with the unmatched chemical resistance of fluoroplastic construction (PTFE or PVDF) for handling the most aggressive acids, alkalis, and organic solvents.
The self-priming design incorporates a gas-liquid separation chamber above the impeller that retains a prime charge, enabling the pump to evacuate air from the suction line and self-prime within 2β3 minutes β without external priming equipment. This makes the pump suitable for above-tank installations, tank draining, and mobile chemical transfer applications.
Applications include concentrated sulfuric acid (up to 98%), hydrochloric acid, nitric acid, sodium hydroxide, chlorinated solvents, and other aggressive media requiring zero metallic contamination.
Product Details
| Type | Self-priming centrifugal |
| Wetted Material | PTFE / PVDF (all wetted parts) |
| Priming Time | < 3 minutes |
| Suction Lift | Up to 7 m |
| Flow Rate | 1 β 100 mΒ³/h |
| Head | 5 β 50 m |
| Media | Concentrated acids, alkalis, solvents, oxidizers |
| Temperature | Up to +120Β°C (PTFE) / +90Β°C (PVDF) |
