Pump
CZ Series Standard Chemical Pump
Pump
CZ Series Standard Chemical Pump
The CZ Series Standard Chemical Pump is manufactured to ISO 2858 and DIN 24256 standards, ensuring full interchangeability with other ISO-compliant pumps worldwide. Designed specifically for the demanding conditions of chemical process plants, the CZ series handles the full spectrum of aggressive chemicals including acids, alkalis, solvents, and oxidizing agents.
Available in a comprehensive range of corrosion-resistant materials: polypropylene (PP), PVDF, glass-reinforced polypropylene (GRP-PP), PTFE-lined carbon steel, stainless steel SS316L, and high-alloy materials for highly aggressive media.
The back-pull-out design allows complete rotor assembly removal for inspection and maintenance without disconnecting the pump from piping.
Specifications
Product Details
| Standard | ISO 2858, DIN 24256, ANSI B73.1 |
| Design | Back pull-out, end-suction, centrifugal |
| Flow Rate | 2 β 500 mΒ³/h |
| Head | 5 β 150 m |
| Material | PP / PVDF / GRP-PP / SS316L / Hastelloy C |
| Seal | Mechanical seal (single / double / cartridge) |
| Temperature | -20Β°C to +120Β°C |
| Application | Chemical process, acid/alkali transfer |
